High Performance and High Recovery Rate.
The variable-speed bucket wheel drive system enhances overall operational performance.
The hydrocyclone and slurry pump deliversuperior performance.
With integrated modular design for sand washing, recovery, and dewatering, it offers easy transportation and quick installation.
The slurry pump and hydrocyclone are lined with high-performance wear-resistant materials, ensuring extended service life and reliable performance.
The high-frequency dewatering screen is equipped with modular polyurethane panels that allow for quick replacement andlow maintenance costs.
Wear-prone areas are treated with wear-resistant materials, reducing maintenance frequency and minimizing downtime.
Capable of handling two grades of sand simultaneously, it works seamlessly with the front-end screening system to meet various operational requirements.
An optional wastewater treatment system can be integrated to achieve zero discharge, preventing secondary pollution.
| Model | Installed power（kW） | Maximum feed size（mm） | Capacity （t/h） | Bucket wheel（mm） | Sludge content（%） | Water supply（m3/h） | Recovery particle size（mm） |
| FWB Series Bucket Wheel Sand Recovery Unit | |||||||
| FWB1520 | 45.5 | 5 | 100-150 | Φ3000×1500 | <15 | 150-220 | >0.075 |
| FWB2030 | 64.6 | 5 | 150-200 | Φ3600×1500 | <15 | 250-300 | >0.075 |
| FWB2540 | 86.6 | 5 | 200-250 | Φ3600×2250 | <15 | 350-400 | >0.075 |
| FWB3050 | 130.5 | 5 | 250-300 | Φ4200×2250 | <15 | 450-500 | >0.075 |
| FWB3560 | 137.5 | 5 | 300-350 | Φ4200×3000 | <15 | 550-600 | >0.075 |
